Conduits & Accessories

Conduits & Accessories

A faithful companion to AKG conduits and pipes. Made only from the highest grade of waterproof and fire-resistant polymers these are absolutely essential for protecting electrical wires and ensuring greater safety to every electrical circuit.

S.No.	Nominal Size (in mm)	Maximum O.D. (in mm)	Minimum O.D. (in mm)	Minimum Internal Diameter
				Light Mechanical Strength (in mm)	Medium Mechanical Strength (in mm)	Heavy Mechanical Strength (in mm)
1	20	20	19.70	17.40	16.90	15.80
2	25	25	24.60	22.10	21.40	20.60
3	32	32	31.60	28.60	27.80	26.60
4	40	40	39.60	35.80	35.40	34.40
5	50	50	49.50	45.10	44.30	43.20
